cnc router from China manufacturer

cnc router

Payment Terms:	T/T,L/C,D/P
Place of Origin:	Shandong, China (Mainland)

Product Detail

Means of Transport: Ocean

Packing: wood crate

Production Capacity: 80 sets/month

Delivery Date: 25-35days

suitable materials of cnc routter:wood,plastic,alloy,marble,alumiunm,PVC,engraving board.

Model		CNC ROUTER TR408
Item	Description	Parameter
1	X, Y, Z working area	1300X2500X200mm
2	Table size	1465X3200mm
3	Resolution	±0.03/300mm
4	Repeatability	± 0.05mm
5	Lathe structure	Steel tube frame
6	X structure	Rack pinion, linear rails
7	Y structure	Rack pinion, linear rails
8	Z structure	Ball Screw, linear rails
9	Max. consume power	12Kw
10	Max. rapid	0-40000mm/min
11	Max. working speed	0-30000mm/min
12	Spindle power motor	8Kw italian HSD spindle with ATC, ER32
13	Spindle speed	0-24000RPM
14	Working mode	Japan panasonic servo System
15	Working voltage	3 phase AC380V/50HZ/60Hz
16	Command code	G code(uoo,mmg)
17	Operating system	Windows Taiwan Syntec system
18	Interface	Internet or USB
19	System Memory	256M (or pendrive)
20	Collet	ER32
21	X, Y working delicacy	<0.02mm
22	Software	Type3 software
23	Running circumstance	Temperature: 0°C~45°C
23	Running circumstance	relative humidity: 30%~75%
24	Packing size	3380x1980x1780mm
25	Net weight	2350KG
26	Gross weight	2550KG
option	Vacuum table	T slot vacuum table
	Vacuum pump	germany becker 4kw 140cbm/h
	dust extractor	3kw double bags
